NorthTech Up Cut Saw (Left) CS20L-1032 In Stock

Name: NorthTech Up Cut Saw (Left) CS20L-1032 In Stock
Brand: Forestly Equipments
SKU: NT-CS20L-1032-SER-NO-1100635
Price: 10159.0 USD
Availability: InStock

10 people are looking at this!

$10,159.00

Save 0% Sold out

Tax included.

NorthTech Up Cut Saw NT CS20L-1032 - LEFT HAND IN STOCK

FEATURES
CUT CAPACITY
SPECS

FEATURES

• 10HP motor, Phase and Voltage: 3ph; 230v/460v; 60Hz wired 230v

• With CE Safety Switch Interlock on Sawblade Door

• Illuminated Guard

• 20” Tungsten Carbide tipped blade included

• 1” Saw arbor diameter

• Cycle operation: Pneumatic

• Quick access on the front of the machine to adjust blade stroke.

• Safety interlock for blade access

• Table size: 20” x 26”

• 2700 RPM

• Net / Gross weight: 788 lbs. / 874 lbs.

• Packing dimensions: (L) 30" x (W) 35" x (H) 51"

• (1) Toolbox and manual

• Warranty is one-year parts

• All machines are tested stateside before shipment providing trouble-free start-up.
CUT CAPACITY

• Cut capacity with Factory Fence: 1" x 14.5", 2" x 14", 3" x 13", 4" x 12", 5" x 11"

• Cut capacity without Factory Fence: 1" x 15.5", 2" x 15-1/8", 3" x 14-3/8", 4" x 13.5", 5-3/4" x 9-1/2"
SPECS

• = Factory

• Main Motor Hp. = 10 hp.

• Voltage/ Freq. = 230 Volt 60Hz

• Phase = 3 Phase

• Amp Requirement = 24.6 Amps

• Electronics = UL Approved Components

• Dual Voltage = 230

• Control Voltage = 24 Volt Control Voltage

• Pass-Line = 36''

• Cut Envelope = 1'' x 15-1/2'', 5-3/4'' x 9-1/

• Max. Width = 17-1/4''

• Max. Thickness = 5-7/8''

• Arbor Rpm = 2700 Rpm

• Blade Size = 20'' Tungsten Carbide Tipped

• No. of Teeth = 120 Tooth

• Tooth Spacing = 1/2''

• Blade Kerf = .141''

• Dust Collection = (1) 4'' @ 450 CFM

• Arbor Diameter = 1'' Arbor

• Cycles/Minute = 40 Cuts Per Minute

• Hold Down Style = T Clamp

• FLR Included = Filter, Lubricator, Regulator

• Recommended CFM = 3/8'' Supply Line @ 90 Psi

• Emergency Stop = Push Button

• Safety Feature = Safety Interlock Switch

• Guarding = High Visibility Guarding

• Operation Style = Pneumatic Foot Pedal

• Fence Type = Adjustable Fence

• Fence Dims. = 2" x 25''

• Worktable Dims. = 21-1/2'' x 67''

• Table Const. = Cast Iron

• Decible Rating = 75 dB

• Net Weight = 788 Lbs.

• Gross Weight = 874 Lbs.

• Machine Dims. = 42'' x 34'' x 54-1/2''

• Packaging Dims = 35'' x 30'' x 51''

Serial #: 1100635
