Starrett 764BXFL Electronic Sheet Metal Micrometer, 6" Throat Depth

Name: Starrett 764BXFL Electronic Sheet Metal Micrometer, 6" Throat Depth
Brand: Forestry Equipments
SKU: 764BXFL
Price: 851.0 USD
Availability: InStock

10 people are looking at this!

$851.00

Save 0% Sold out

Tax included.

764, 764M Electronic Digital Sheet Metal Micrometers

Digital Sheet Metal Micrometer, Friction Thimble, Carbide Anvil, .00005", 0-1" Range

DESCRIPTION
FEATURES
SPECS
DOWNLOADS
WARNING

DESCRIPTION

The Starrett 764 Series Electronic Sheet Metal Micrometer is a full-featured precision measuring tool built with customary Starrett quality and workmanship. The 764 series includes a large, easy-to-read, high-contrast LCD digital readout for clear readings. Equipped with Flat anvils that gives a point contact for more accurate gaging. Includes 6" Throat Depth with Standard Inch Graduations on Shell and Thimble. Its no-glare satin chrome finish minimizes annoying surface glare under bright lights indoors or filters out UV light. This model features 0.00005"in & 0.001mm resolution and 0-1"in & 0-25mm measuring range. Starrett electronic micrometers guarantee a precise measurement at every position each and every time. 6" Throat Depth, 0-1" (0-25mm) Range, Flat Anvil, with Output, Carbide Faces.
FEATURES

• Large, easy-to-read, high-contrast LCD digital readout

• Rigid one-piece frame of drop forged steel, ribbed for strength and stability

• Extremely hard and stable one-piece spindle

• Micro-lapped measuring face

• Starrett satin chrome finish - no glare - resists rust

• Advanced sleeve design with staggered lines and distinct figures for precise and easy readability

• Combination ratchet and speeder for uniform pressure and quicker adjustment
SPECS

• Made in America: Yes

• Micrometer Type: Electronic Sheet Metal Micrometer (with output)

• Range (in): 0-1"

• Range (mm): 0-25mm

• Resolution (in): .00005"

• Resolution (mm): 0.001mm

• Anvil/Spindle Material: Carbide

• Anvil Type: Flat

• Spindle Type: Flat

• Lock Nut Type: Knurled Ring Type

• Thimble Type: Friction
DOWNLOADS

2D Dimensional drawing
CALIFORNIA PROPOSITION 65 WARNING

WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer, and birth defects, or other reproductive harm. For more information go to: www.P65Warnings.ca.gov

Catalog Number: 81-141J

EDP Number: 53400
